Introduction to Bold BI Data Sources

introduction to bold bi data sources

Data sources are the building blocks of the dashboards that power data visualization. A data source can be a file, a database on a DBMS, or even a live data feed. In this article, we are going to see how to create data sources from different connection types and how to manage and share them with other users in the Bold BI application.

If you are new to the Bold BI Dashboardsregister for a free trial on our website. At the end of the registration process, you will reach the following page view.

homepage view in Bold BI dashboards for illustrating the Bold BI data sources
Homepage view in Bold BI Dashboards

What data sources are supported in Bold BI?

Bold BI supports a wide range of data connections from Excel files to the Azure SQL data warehouse. The following are the different types of data connections supported:



Bold BI has an internal data store where you can import data to build your dashboard. All the NoSQL databases, files, and REST API connections work in the extract mode, where the data is extracted and moved into the data store. You can configure refresh settings so that the data is periodically updated in the data store.

The SQL databases, on the other hand, can work in both extract and live mode.

Architecture of Bold BI Data Sources
Data source architecture



How do I create a data source?

You can create a new data source from the home page, data sources listing page, or from the dashboard designer itself.

Create a new data source from Bold BI home page
Create a new data source from home page



create a new data source from listing page
create a new data source from listing page



Create a new data source from the Bold BI dashboard designer
Create data source from dashboard designer

In the home page, click Create and select Data Sources to open the list of connections. Bold BI supports more than 80 different data connections, as shown in the following image.

List of available data connections in Bold BI
List of data connections

Choose one of the connections in the list and provide the connection and the authentication details in the connection wizard, as shown in the following.

Data source creation wizard
Data source creation wizard

Click Connect to establish the connection. Upon successful connection, the application will navigate to the data source designer page.

Bold BI data source designer
Data source designer

The data source designer is where you can add simple transformations to your data and format them for use in visualizations. The following transformations are supported:

Drag and drop at least one table, apply transformations if required, and then save the data source by clicking the Save and Exit option. All your saved data sources can be found on the data source listing page.

Data source listing page in Bold BI application
Data source listing

The created data source can then be used in building your custom business dashboards. Now let’s see how to work with the different connection types in detail.

Creating a file connection

While adding a file connection, the data is extracted and moved to the built-in data store for advanced data processing. The size of the data store may vary based on your subscription plan. The following file types are supported in the application.

  • Text
  • Microsoft Excel
  • CSV
  • JSON
  • XML

To create a static file connection, upload your file (limited to 75 MB) through the connection wizard and click the Preview & Connect option. In the case of Excel, each sheet is represented as a separate table, as shown in the following preview pane.

File connection preview pane in Bold BI connection wizard
File connection – preview pane

Choose only the tables and columns you will be using in the dashboard and then click Connect. The selected tables and columns will be extracted to the data store.

To use files with dynamic content, use one of the cloud file-sharing services like Google Drive or Dropbox. In the data connections list, choose your connection (OneDrive in the example) and authenticate the connection.

Configuring OneDrive connection in Bold BI wizard
OneDrive connection wizard

From the file picker, choose a file from one of the supported file formats and configure the refresh settings as shown in the following image. For CSV files, choose the delimiter (comma, tab, semicolon).

Configuring refresh settings in OneDrive connection wizard
Configuring refresh settings

When the refresh settings are configured, the data will be updated in the mentioned refresh cycle to help you keep your dashboard updated with the latest data.

Creating a SQL database connection

You can create dashboards from the data on your on-premise server by selecting the required connection from the list. The SQL connections can work for both live and extracted modes.

By default, the SQL connections work on the live mode as shown in the following image. You can add the server details and authentication, and then connect with the database. Please make sure to white list the following IP addresses to avoid service disruptions:

  • 52.234.209.94
  • 52.234.228.143
  • 52.234.230.214
  • 52.234.224.254
  • 52.234.225.60
  • 52.234.231.3
  • 52.234.229.253
  • 52.234.228.68



When connected in live mode, the dashboard always shows the live data when you open or refresh the dashboard.

Configuring SQL connection in live mode
SQL connection in live mode

You can also extract the data from your SQL databases, move it to the data store, and build the dashboard from it. To connect in extract mode, select the Extract radio button and connect to your database. You can also choose the refresh time interval to move the latest data into the data store in periodic intervals.

Configuring SQL connection in extract mode
Configuring SQL connection in extract mode



In the extract mode, during every refresh cycle the selected tables will be dropped and the data will be freshly pulled from the database and moved into the data store. You can also configure incremental refreshes to fetch only the modified or new rows into the data store. This could highly reduce the time taken to refresh the data. To configure incremental refreshes, select the column with the timestamp as shown in the following image.

Configuring incremental refresh settings for extract mode
Configuring incremental refresh settings

Once configured, click Connect to take you to the data source designer where you can transform and save the data source.

Creating a Web API connection

You can connect to any web data source using RESTful APIs. Bold BI has a generic Web API connector you can use to connect to the web data sources using GET/POST methods. The connector also allows you to add request headers and parameters.



Bold BI generic Web API connector
Generic Web API connector



The connector lets you retrieve responses in JSON, CSV, or XML formats and allows basic HTTP authentication or open connections through No Authentication mode.

Bold BI connections wizard for Web API
Web API connection wizard



Make sure you always have the latest data in your data source by configuring the Refresh Settings to the desired time interval.

For other known connections, such as Salesforce or Zendesk, you can use the native connectors available in the wizard. The native connectors are specifically designed for the connection and come with preconfigured headers, URLs, and parameters wherever applicable.

Native connector for JIRA application
Native connector for JIRA

Creating an OAuth connection

Bold BI provides SSO (Single Sign-On) support for web connections such as Salesforce and Smartsheet. This requires OAuth authentication.

To create a data source from an OAuth connection, just select the required connection from the list and enter your login credentials. Once the authentication is successful, the application will navigate to the wizard where you can add your REST API (SOQL query for Salesforce), refresh settings, etc., and create a connection just like the other Web API connections.

Additionally, Bold BI preserves your authentication (access token and refresh token) details in the application securely to help you build more dashboards from it without having to sign in again. You can access these authentication details from the profile page of your application as shown in the following image.

ingle sign-On support for OAuth data connections
SSO support for OAuth data connections



For a token expiration or password change, you can re-authorize the connections from here. Click the menu on the right side of your connection and choose the option Reauthorize.

Reauthorize OAuth connection types in Bold BI
Reauthorize OAuth connection types

By reauthorizing the connection, all the dashboards that use the connection will be refreshed in a single action and the dashboard can show the metrics without any disruption.

Combining multiple data sources

Combining data from multiple sources is a major requirement with the usage of various online applications. A good example is measuring email campaign performance using data from Mailchimp and Salesforce.

Bold BI allows you to combine multiple data sources when they are in extract mode. The extracted tables can be joined to build interactive dashboards. To combine multiple data sources, use the Shared Tables panel at the bottom of the data source designer. All the extracted tables you own and those shared with you are listed in the Shared Tables panel. You can drag them to the canvas, as shown in the image, to join them.

Option to combine multiple data sources in Bold BI applicatiion
Combining multiple data sources



Sharing data sources

You can share your data sources with other users in the application to let them build dashboards from them. To share a data source with another user, go to the data sources listing and choose Sharing Permissions from the menu, as shown in the following image.

Sharing a data source within Bold BI application
Sharing a data source



In the Sharing Permissions dialog, you can choose users or groups with whom to share the data source and specify the access permissions.  For example, you can be the owner for the data source and not let others edit it, but allow them to build dashboards from it using the Read access mode.

Permission management while sharing data sources
Permission Management



Editing a data source

To edit a data source, choose Edit Data Source from the listing menu, as shown in the following image. Keep in mind, once you edit and resave the data source, the changes will affect all the dashboards that use the data source in a shared mode.

Editing a data source
Editing a data source

Conclusion

We hope this article helped you to kick-start building your own dashboard with the data you have. For any questions, please contact us through the comments section below. You can also contact us by submitting your queries here or, if you already have a Bold BI account, please login to submit your support query. Bold BI dashboards now comes with a 15-day free trial with no credit card information required. We welcome you to start a free trial and experience Bold BI for yourself.
